Welcome to graphreduce

GraphReduce is an abstraction layer for doing batch feature engineering spanning many tables. The library abstracts away much of the tedious, repetitive work such as point in time correctness, dealing with cardinality, prefixing columns, joins, swapping between compute layers, and more. We use graphs with networkx to represent tables as nodes and relationships as edges, allowing most data storage formats and compute layers to be modeled.

Despite many advancements in generative, preparing ML/AI-ready datasets remains a challenge at scale. There is very interesting work coming out of Relbench, but we are not there yet. A few inspirations for this project:

Key features

  • Cutomizable: abstractions allow feature implementations to be customized. While many will opt for automated feature engineering, deduplication, anomalies, entity resolution, and others may need custom or third-party library support.
  • Interoperable: supports pandas, pyspark, and dask dataframe APIs and SQL dialects for Redshift, Athena, SQLite, Databricks SQL (Snowflake in progress).
  • Composable: by using graphs as the underpinning data structure with networkx we allow arbitrarily large feature engineering pipelines by doing depth first traversal based on cardinality.
  • Scalable: support for different computational backends and checkpointing allow for massive feature engineering graphs to be constructed and executed with a compute push down paradigm
  • Automated: by leveraging and extending ideas from research such as Deep Feature Synthesis we support fully automated feature engineering.
  • Point in time correctness: requirements that time-series data to have a date key, allowing for point in time correctness filtering to be applied across all data / nodes in the compute graph.
  • Production-ready: since batch feature engineering pipelines require a computational graph defined, this makes transition to production deployments
  • Cardinality awareness: in most tabular datasets cardinality needs to be handled carefully to avoid duplication and proper aggregation - graphreduce makes this a breeze.

Installation

with pip

pip install graphreduce

from source

git clone https://github.com/wesmadrigal/graphreduce
cd graphreduce && pip install -e .

Basic usage

import datetime
import pandas as pd
from graphreduce.node import GraphReduceNode, DynamicNode
from graphreduce.enum import ComputeLayerEnum, PeriodUnit
from graphreduce.graph_reduce import GraphReduce

# source from a csv file with the relationships
# using the file at: https://github.com/wesmadrigal/GraphReduce/blob/master/examples/cust_graph_labels.csv
reldf = pd.read_csv('cust_graph_labels.csv')

# using the data from: https://github.com/wesmadrigal/GraphReduce/tree/master/tests/data/cust_data
files = {
    'cust.csv' : {'prefix':'cu'},
    'orders.csv':{'prefix':'ord'},
    'order_products.csv': {'prefix':'op'},
    'notifications.csv':{'prefix':'notif'},
    'notification_interactions.csv':{'prefix':'ni'},
    'notification_interaction_types.csv':{'prefix':'nit'}

}
# create graph reduce nodes
gr_nodes = {
    f.split('/')[-1]: DynamicNode(
        fpath=f,
        fmt='csv',
        pk='id',
        prefix=files[f]['prefix'],
        date_key=None,
        compute_layer=GraphReduceComputeLayerEnum.pandas,
        compute_period_val=730,
        compute_period_unit=PeriodUnit.day,
    )
    for f in files.keys()
}
gr = GraphReduce(
    name='cust_dynamic_graph',
    parent_node=gr_nodes['cust.csv'],
    fmt='csv',
    cut_date=datetime.datetime(2023,9,1),
    compute_layer=GraphReduceComputeLayerEnum.pandas,
    auto_features=True,
    auto_feature_hops_front=1,
    auto_feature_hops_back=2,
    label_node=gr_nodes['orders.csv'],
    label_operation='count',
    label_field='id',
    label_period_val=60,
    label_period_unit=PeriodUnit.day
)
# Add graph edges
for ix, row in reldf.iterrows():
    gr.add_entity_edge(
        parent_node=gr_nodes[row['to_name']],
        relation_node=gr_nodes[row['from_name']],
        parent_key=row['to_key'],
        relation_key=row['from_key'],
        reduce=True
    )


gr.do_transformations()
2024-04-23 13:49:41 [info     ] hydrating graph attributes
2024-04-23 13:49:41 [info     ] hydrating attributes for DynamicNode
2024-04-23 13:49:41 [info     ] hydrating attributes for DynamicNode
2024-04-23 13:49:41 [info     ] hydrating attributes for DynamicNode
2024-04-23 13:49:41 [info     ] hydrating attributes for DynamicNode
2024-04-23 13:49:41 [info     ] hydrating attributes for DynamicNode
2024-04-23 13:49:41 [info     ] hydrating attributes for DynamicNode
2024-04-23 13:49:41 [info     ] hydrating graph data
2024-04-23 13:49:41 [info     ] checking for prefix uniqueness
2024-04-23 13:49:41 [info     ] running filters, normalize, and annotations for <GraphReduceNode: fpath=notification_interaction_types.csv fmt=csv>
2024-04-23 13:49:41 [info     ] running filters, normalize, and annotations for <GraphReduceNode: fpath=notification_interactions.csv fmt=csv>
2024-04-23 13:49:41 [info     ] running filters, normalize, and annotations for <GraphReduceNode: fpath=notifications.csv fmt=csv>
2024-04-23 13:49:41 [info     ] running filters, normalize, and annotations for <GraphReduceNode: fpath=orders.csv fmt=csv>
2024-04-23 13:49:41 [info     ] running filters, normalize, and annotations for <GraphReduceNode: fpath=order_products.csv fmt=csv>
2024-04-23 13:49:41 [info     ] running filters, normalize, and annotations for <GraphReduceNode: fpath=cust.csv fmt=csv>
2024-04-23 13:49:41 [info     ] depth-first traversal through the graph from source: <GraphReduceNode: fpath=cust.csv fmt=csv>
2024-04-23 13:49:41 [info     ] reducing relation <GraphReduceNode: fpath=notification_interactions.csv fmt=csv>
2024-04-23 13:49:41 [info     ] performing auto_features on node <GraphReduceNode: fpath=notification_interactions.csv fmt=csv>
2024-04-23 13:49:41 [info     ] joining <GraphReduceNode: fpath=notification_interactions.csv fmt=csv> to <GraphReduceNode: fpath=notifications.csv fmt=csv>
2024-04-23 13:49:41 [info     ] reducing relation <GraphReduceNode: fpath=notifications.csv fmt=csv>
2024-04-23 13:49:41 [info     ] performing auto_features on node <GraphReduceNode: fpath=notifications.csv fmt=csv>
2024-04-23 13:49:41 [info     ] joining <GraphReduceNode: fpath=notifications.csv fmt=csv> to <GraphReduceNode: fpath=cust.csv fmt=csv>
2024-04-23 13:49:41 [info     ] reducing relation <GraphReduceNode: fpath=order_products.csv fmt=csv>
2024-04-23 13:49:41 [info     ] performing auto_features on node <GraphReduceNode: fpath=order_products.csv fmt=csv>
2024-04-23 13:49:41 [info     ] joining <GraphReduceNode: fpath=order_products.csv fmt=csv> to <GraphReduceNode: fpath=orders.csv fmt=csv>
2024-04-23 13:49:41 [info     ] reducing relation <GraphReduceNode: fpath=orders.csv fmt=csv>
2024-04-23 13:49:41 [info     ] performing auto_features on node <GraphReduceNode: fpath=orders.csv fmt=csv>
2024-04-23 13:49:41 [info     ] joining <GraphReduceNode: fpath=orders.csv fmt=csv> to <GraphReduceNode: fpath=cust.csv fmt=csv>
2024-04-23 13:49:41 [info     ] Had label node <GraphReduceNode: fpath=orders.csv fmt=csv>
2024-04-23 13:49:41 [info     ] computed labels for <GraphReduceNode: fpath=orders.csv fmt=csv>

gr.parent_node.df
cu_id   cu_name notif_customer_id   notif_id_count  notif_customer_id_count notif_ts_first  notif_ts_min    notif_ts_max    ni_notification_id_min  ni_notification_id_max  ni_notification_id_sum  ni_id_count_min ni_id_count_max ni_id_count_sum ni_notification_id_count_min    ni_notification_id_count_max    ni_notification_id_count_sum    ni_interaction_type_id_count_min    ni_interaction_type_id_count_max    ni_interaction_type_id_count_sum    ni_ts_first_first   ni_ts_first_min ni_ts_first_max ni_ts_min_first ni_ts_min_min   ni_ts_min_max   ni_ts_max_first ni_ts_max_min   ni_ts_max_max   ord_customer_id ord_id_count    ord_customer_id_count   ord_ts_first    ord_ts_min  ord_ts_max  op_order_id_min op_order_id_max op_order_id_sum op_id_count_min op_id_count_max op_id_count_sum op_order_id_count_min   op_order_id_count_max   op_order_id_count_sum   op_product_id_count_min op_product_id_count_max op_product_id_count_sum ord_customer_id_dupe    ord_id_label
0   1   wes 1   6   6   2022-08-05  2022-08-05  2023-06-23  101.0   106.0   621.0   1.0 3.0 14.0    1.0 3.0 14.0    1.0 3.0 14.0    2022-08-06  2022-08-06  2023-05-15  2022-08-06  2022-08-06  2023-05-15  2022-08-08  2022-08-08  2023-05-15  1.0 2.0 2.0 2023-05-12  2023-05-12  2023-06-01  1.0 2.0 3.0 4.0 4.0 8.0 4.0 4.0 8.0 4.0 4.0 8.0 1.0 1.0
1   2   john    2   7   7   2022-09-05  2022-09-05  2023-05-22  107.0   110.0   434.0   1.0 1.0 4.0 1.0 1.0 4.0 1.0 1.0 4.0 2023-06-01  2023-06-01  2023-06-04  2023-06-01  2023-06-01  2023-06-04  2023-06-01  2023-06-01  2023-06-04  2.0 1.0 1.0 2023-01-01  2023-01-01  2023-01-01  3.0 3.0 3.0 4.0 4.0 4.0 4.0 4.0 4.0 4.0 4.0 4.0 NaN NaN
2   3   ryan    3   2   2   2023-06-12  2023-06-12  2023-09-01  NaN NaN 0.0 NaN NaN 0.0 NaN NaN 0.0 NaN NaN 0.0 NaT NaT NaT NaT NaT NaT NaT NaT NaT 3.0 1.0 1.0 2023-06-01  2023-06-01  2023-06-01  5.0 5.0 5.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 NaN NaN
3   4   tianji  4   2   2   2024-02-01  2024-02-01  2024-02-15  NaN NaN 0.0 NaN NaN 0.0 NaN NaN 0.0 NaN NaN 0.0
